Polygon Collosus N9

RELEASE THE BEAST

Ride faster, track better, leave them in the dust

The Polygon Collosus N is the ultimate enduro beast, creayed to conquer the toughest terrains. With 170mm of suspension travel, a rugged frame, and 29-inch wheels, this bike is built for everything from enduro races to bike park laps. It’s the ideal choice for riders seeking unmatched performance and durability on challenging trails.

Frameset
Frameset
ALX ENDURO 170mm TRAVEL

Fork
FOX 38 FLOAT PERFORMANCE, AIR SPRING, 170mm TRAVEL, OFFSET: 44mm, W/ FENDER

Rear Shock
FOX FLOAT X2, AIR SPRING, 2 POSITION ADJUST, HSC-LSC, HSR-LSR, E2E: 230x65mm

Frame Color
BURGUNDY RED

Decal Color
MAGENTA PINK

Drivetrain
Shifter
SHIMANO XT SL-M8100-R, 1x12-SPEED TRIGGER

Crank
SHIMANO DEORE XT FC-M8120, 32T

Cassette
SHIMANO SLX CS-M7100, 10-51T

Rear Derailleur
SHIMANO XT RD-M8100-SGS

BB
SHIMANO BB-MT501 BSA THREADED

Chain
KMC X-12

Pedal
ALLOY FLAT W/ REPLACEABLE PIN

Cockpit
Saddle
LINC XTENT, CR-MO ø7mm

Seatpost
TRANZ X JD-YSP39KL 150mm (S, M) / 170mm (L, XL) TRAVEL, DxL: 34.9 x 456mm (S, M) / 495mm (L, XL)

Handlebar
RACE FACE CHESTER 35, W: 780mm, BB: 35mm, R/D: 35mm, B: 8degree

Handlestem
RACE FACE AEFFECT R 35, EXT: 40mm, BB: 35mm, R/D: 0degree

Headset
FSA NO.57E W/ SEALED BEARING, ZS 44/28.6 | ZS 56/40

Wheel & Tire
Wheel Set
POLYGON MT6 TUBELESS READY

Wheel Size
29"

Tire
MAXXIS ASSEGAI 29"x2.5"

Rim
F: ALLOY DOUBLE WALL H:18mm W: 30mm 622-30 32H FOR TYRE 622-54/76 TL READY / R: ALLOY DOUBLE WALL H:18mm W: 30mm 622-30 32H FOR TYRE 622-54/76 TL READY

Hub
F: SHIMANO XT HB-M8110-B BOOST 15x110mm 32H CL / R: SHIMANO DEORE XT FH-M8110-B BOOST 12x148mm 32H CL FOR MICRO SPLINE

Spokes
F: 14G STAINLESS NDS:290mm DS:292mm W/ 12mm BRASS NIPPLE / R: 14G STAINLESS NDS:294mm DS:292mm W/ 12mm BRASS NIPPLE

Brake
Brake Lever
SHIMANO XT BL-M8100

Brake Caliper
SHIMANO XT HYDRAULIC DISC

Rotor
SHIMANO SM-RT64 203mm


 S M L XL
Height (cm) 155-165 165-175 175-185 185-195
Seat Tube Length (A) 390 400 415 430
Seat Tube Angle (B) 70 70 70 70
Effective Seat Tube Angle (C) 77 77 77 77
Head Tube Length (D) 100 105 110 120
Head Tube Angle (E) 63.5 63.5 63.5 63.5
Effective Top Tube (F) 583.6 604.6 626.4 647.7
Bb Height (G) 353 353 353 353
Bb Offset (H) 27 27 27 27
Chainstay Length (I) 435 435 435 435
Wheelbase (J) 1221.7 1244 1266.2 1290.7
Frame Reach (K) 440 460 480 500
Frame Stack (L) 625.5 630 634.5 643.4
Standover Height (M) 710 716 717 720

Select Size
From $980.08

Original: $2,800.22

-65%
Polygon Collosus N9—

$2,800.22

$980.08
